Toyota CAMRY 后雾灯 — Figure 8116
Toyota CAMRY EPC diagram 8116, 后雾灯, with 1 images and 5 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 81210C | Rear fog light bulb | 99132-11210 |
| 81210R | Rear fog light assembly | 81210-39095 · 81210-39096 · 81220-39045 · 81220-39046 |
| 81211R | Rear fog light cover | 81211-32010 · 81211-32011 · 81221-32010 · 81221-32011 |
| 81212R | No. 1 rear fog light gasket | 81212-32010 · 81512-20181 |
| 81213R | No. 2 rear fog light gasket | 81214-32010 |
