Toyota CAMRY accelerator pedal connecting rod — Figure 7801
Toyota CAMRY EPC diagram 7801, accelerator pedal connecting rod, with 1 images and 4 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 78107 | Accelerator pedal torque rod bracket sub-assembly | 78108-06020 |
| 78110K | Accelerator pedal connecting rod assembly with sensor | 78110-06230 · 78110-06240 |
| 78114A | accelerator pedal bracket | 78114-06030 |
| 78118 | accelerator pedal pad | 78117-06050 |
