Toyota CAMRY 警示铭牌(车外和车内) — Figure 7403
Toyota CAMRY EPC diagram 7403, 警示铭牌(车外和车内), with 1 images and 12 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 11291B | Engine name plate | 11291-36040 |
| 11293D | engine warning label | 11293-36070 |
| 16793E | Cooling fan warning label | 16793-28020 |
| 69339C | Child Restraint Information Label | 69339-06080 |
| 74515A | Anti-theft warning nameplate | 74515-06020 |
| 74579A | Unleaded Fuel Information Label | 74579-0D010 · 74579-26010 · 74579-26011 |
| 74596A | Side air bag warning label | 74596-53020 |
| 74598A | Passenger air bag warning label | 74598-06040 |
| 74751 | tire pressure information label | 42661-06870 · 42661-06880 · 42661-06A70 · 42661-06A80 |
| 88723E | Cooler maintenance warning label | 88723-06110 · 88723-0D020 |
| G9275 | No. 1 battery warning label | G9275-76030 |
| G9288A | Battery charging precautions label | G9288-47090 |
