Toyota CAMRY Floor stringers — Figure 5305
Toyota CAMRY EPC diagram 5305, Floor stringers, with 1 images and 40 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 53704D | Battery left side bracket sub-assembly | 53704-33020 |
| 57016 | Right front longitudinal beam reinforcement sub-assembly | 57016-33030 · 57016-33040 |
| 57017 | Left front longitudinal beam reinforcement sub-assembly | 57017-33040 |
| 57101 | Right front longitudinal beam sub-assembly | 57101-33900 |
| 57102 | Left front longitudinal beam sub-assembly | 57102-33900 |
| 57103A | Floor No. 3 beam sub-assembly | 57103-33030 · 57103-33051 |
| 57105 | Right front suspension cross member front mounting bracket sub-assembly | 57105-28120 |
| 57106E | Left front suspension cross member front mounting bracket sub-assembly | 57106-28120 |
| 57111 | Right front longitudinal beam | 57111-33020 |
| 57112 | Left front longitudinal beam | 57112-33030 |
| 57113 | Right front longitudinal beam extension | 57107-33030 · 57107-33031 |
| 57114 | Left front longitudinal beam extension | 57108-33030 · 57108-33031 |
| 57115A | Right front longitudinal beam outer panel | 57115-33030 |
| 57116A | Left front longitudinal beam outer panel | 57116-33020 |
| 57117B | Install reinforcement on the right side of the front bumper | 57117-33050 |
| 57118A | Install reinforcement on the left side of the front bumper | 57118-33050 |
| 57151A | No. 1 right front longitudinal beam reinforcement | 57151-33020 |
| 57152 | No. 1 left front longitudinal beam reinforcement | 57152-33030 |
| 57155 | No. 3 right front longitudinal beam reinforcement | 57155-33030 |
| 57156 | No. 3 left front longitudinal beam reinforcement | 57156-33030 |
| 57167E | Front cross member right corner panel | 57167-33020 |
| 57168E | Front cross member left corner panel | 57168-33020 |
| 57197 | Right front torsion box section piece | 57077-33040 |
| 57198 | Left front anti-torsion box section piece | 57078-33040 |
| 57249 | No. 1 Flexible Hose Bracket | 57249-10040 |
| 57249A | No. 1 Left Flexible Hose Bracket | 57249-10040 |
| 57401 | Main floor right longitudinal beam sub-assembly | 57401-33100 |
| 57402 | Main floor left longitudinal beam sub-assembly | 57402-33100 |
| 57417 | Front floor lower right reinforcement | 57419-33040 |
| 57418 | Front floor lower left reinforcement | 57419-33040 |
| 57451B | Front floor right cross member | 57451-33050 · 57451-33051 |
| 57452 | Front floor left cross member | 57452-33020 · 57452-33021 |
| 57475E | Front floor right cross member panel | 57475-33010 |
| 57476C | Front floor left cross member panel | 57476-33010 |
| 57601 | Rear floor right longitudinal beam sub-assembly | 57601-33905 |
| 57602 | Rear floor left longitudinal beam sub-assembly | 57602-33904 |
| 57605B | Rear floor No. 1 cross member sub-assembly | 57605-33060 · 57605-33061 |
| 57606C | Rear floor No. 2 cross member sub-assembly | 57606-33090 · 57606-33130 |
| 57615A | Rear floor right rear longitudinal member | 57615-33906 |
| 57616A | Rear floor left rear longitudinal member | 57616-33904 |
