Toyota CAMRY 后防护条 — Figure 7504
Toyota CAMRY EPC diagram 7504, 后防护条, with 2 images and 8 PNC and OE references.
PNC and OE references
| PNC | Part name | OE numbers |
|---|---|---|
| 75081A | Rear door decorative panel sub-assembly | 75081-39035 · 75081-39085 |
| 75571 | Protective strips on the outside of the rear window | 75571-32010 · 75571-32020 |
| 75572 | Protective strip under rear window | 75575-32010 · 75575-32011 · 75575-32020 |
| 75573 | Right protective strip on rear window side | 75573-32010 · 75573-32020 |
| 75574 | Protective strip on the left side of the rear window | 75574-32010 · 75574-32020 |
| 75577 | Protective strip on the lower right corner of the back window | 75583-32010 |
| 75578 | Protective strip at lower left corner of rear window | 75584-32010 |
| 75821 | Trunk door rear protective strip | 75813-32010 · 75813-32020 |
